The aggregate crushing value provides a relative measure of the resistance of an aggregate to crushing under a gradually applied compressive load. Supplied complete with cylinder, plunger, base plate, tamping rod, and measure.
AC-150 Aggregate Crushing Value Apparatus
comprising
150 mm nominal diameter steel cylinder, plunger and base plate. Weight: 16.6 kg
Metal Measure 115 mm diameter x 180 mm deep.
Weight: 870 g
Tamping Rod 16 mm diameter x 600 mm long with rounded end.
AC-75 Aggregate Crushing Value Apparatus
comprising
75 mm nominal diameter steel cylinder, plunger and base plate. Weight: 3.5 kg
Metal Measure 57 mm diameter x 90 mm deep.
Tamping Rod 8 mm diameter x 300 mm long with rounded end. Weight: 350 g
