The Pendulum Skid Tester measures the frictional resistance between a rubber slider mounted on the end of a pendulum arm and the test surface. This provides highway engineers with a routine method of checking the resistance of wet and dry surfaces to slipping and skidding, both in the lab and on site.

Specifications:
1, Rocker weight: 1500±30g
2, Distance between rocking centre and center of gravity : 410±5mm
3, Positive static pressure on pavement: 22.2±0.5kN

4, Package:Flight Case

5, Package dimension：770mm*780mm*510mm

6，Net weight of tester: 17kgs

7, Gross weight approx: 45kgs

Standard:

BS EN 1097-8 determination of polished stone value

AS/NZS 4586:1999 slip resistance classification of new pedestrian surface materials

BS 6077 Pt1 clay and calcium silicate pavers for flexible pavements

BS 7044 artificial sports surfaces: person/surface interaction

BS7188 impact absorbing playground surfaces

BS 8204 in-situ fl ooring, part 3 code of practice for polymer modified cementitous wearing surfaces ASTM E303 standard method for measuring surface frictional properties using british pendulum

BS 7976 method of operation and calibration of the pendulum tester

EN 1436: 1997 road marking materials

BS EN 13036-4:2003 road and airfield surface characteristics

BS 812 Pt. 144

• Designed for laboratory and in situ road surface testing

• Dispatched calibrated to ASTM E-303

• Low friction arm, and lightweight pointe

• Comes with integral ‘F’ scale for use with small slider set for 76mm slide length. (PSV test)

• Repeatable and reproducible

• Supplied with robust carrying case

STANDARD DELIVERY:

48-B0192 Portable skid resistance and friction tester, adjustable in height

B0192/1 Sturdy case with dense foam inserts giving  excellent protection

B0192/2 F’ Scale Built in, for use with small slider set for 76mm slide length. (PSV test)

B0192/3 Perspex setting gauge 126 mm

B0192/4 TRRL3.0, Slider 55 Road surfaces. Customer can choose either type.

B0192/5 Brush, For removing unwanted dirt or grit from area to be tested

B0192/6 C Spanner, For attaching and releasing arm to rotating head

B0192/7 17mm Spanner For fitting rear foot

B0192/8 Water spray bottle, For wetting surface to be tested

B0192/9 Feet pads, For placing under levelling feet when on soft ground

B0192/10 Operating instructions, A guide to road, floor and PSV testing

B0192/11 Tool set

B0192/12 Calibration Certificate Despatched

OPTIONS:  need to be ordered seperately

B0192/13 Metal base plate without fixing device

B0192/14 TRRL 1.250, Slider 55 PSV Test

B0192/15 FOUR S, Slider 96 Internal Floors

B0192/16 Fixing device to base for blocks and nature stones(EN1341,1342)

B0192/17 Fixing device to base for laboratory polished test
