C192 –AASHTO T23, T126
Concete vibrator
TX series internal concrete vibrators, using the pendulum principle, 3000rpm of the devices unit translates via the flexible shaft into 12,000 vibrations per minute in the poker head. The low output speed ensures high reliability and extended services life, can be used between two types of
drive units (interchangeable): electrical motor and petrolor engine drive units’ series, with standard poker diameters.
Model No | Diameter
| Vibrating frequency
| Outside Dia of Flexible Hose(mm)
| Inner Dia of Flexible Hose(mm)
| Length(m)
| Max. vibration Force (KN)
| Vibrating Amplitude (mm)
| Available Motor or engine
|
TX35 | 35 | 183 | 30 | 15 | 1 to 12 | 5.293 | 1.15 | Electric motor, Gasoline Engine,CD-CI Engine
|
TX50 | 50 | 183 | 36 | 20 | 1 to 12 | 6.251 | 1.21 | |
TX70 | 70 | 183 | 36 | 20 | 1 to 12 | 7.157 | 1.32 | |
TX28 | 28 | 183 | 30 | 15 | 1 to 12 | 4.846 | 1.11 | |
TX32 | 32 | 184 | 30 | 15 | 1 to 12 | 5.104 | 1.13 | |
TX38 | 38 | 185 | 30 | 15 | 1 to 12 | 5.485 | 1.18 | |
TX45 | 45 | 186 | 32 | 17 | 1 to 12 | 5.932 | 1.2 | |
TX60 | 60 | 187 | 36 | 20 | 1 to 12 | 6.704 | 1.28 |
