Flakiness Index Sieve
Aggregate particles are considered as flaky when their thickness is less than 0.6 of their mean sieve size. Aggregate to be classified is separated into seven sieve fractions from 6.3 to 63 mm and each fraction is examined separately. The dimensions of each sieve comply with the relevant International Standard, manufactured from heavy gauge steel sheet and coated with electrostatic paint.
The accuracy of the slot size is better than 0.1 mm.
47-D0415Flakiness sieve test set including: 4.9x30, 7.2x40, 10.2x50, 14.4x60, 19.7x80, 26.3x90, and 33.9x100 mm slot sieves.
47-D0415/1 4.9x30 mm slot
47-D0415/2 7.2x40 mm slot
47-D0415/310.2x50 mm slot
47-D0415/4 14.4x60 mm slot
47-D0415/5 19.7x80 mm slot
47-D0415/6 26.3x90 mm slot
47-D0415/7 33.9x100 mm slot
