Home > Soil > Dynamic Cone Penetration Test
Motor operated dynamic cone penetrometer
Motor operated dynamic cone penetrometer
Motor operated dynamic cone penetrometer
Motor operated dynamic cone penetrometer
Motor operated dynamic cone penetrometer
Item No.16-T0012/D
MOTOR OPERATED DYNAMIC CONE PENETROMETER
(DCP) 16-T0012/D 20kg or 30kg hammer, 57.5 cm. fall
Standard: ASTM D 6951-03
Description
Key Features
Specifications
Accessories

MOTOR OPERATED DYNAMIC CONE PENETROMETER
(DCP) 16-T0012/D 20kg or 30kg hammer, 57.5 cm. fall
Standard: ASTM D 6951-03

• The apparatus comprises a 4 stroke engine which drives, through a fl exible shaft, the lifting mechanism, a
20 kg weight, a 10 kg supplementary weight, 10 rods, 5 cones each of 500 and 1000 mm2 size, and rod lifting
device.
• Accessory 16-T0012/D7 Tripod to make easier the use of the apparatus.
• 1.9 kW 4 stroke engine
• Driving rate: up to 45 blows/min
• One year warrantee against any manufacturing defects.
