TPZ-1 sieve shaker

Vibrating Screen is a latest laboratory automatic screen designed and developed by our factory, applied to particle analysis in the fields of pharmacy, metallurgy, foods,cosmetics and grain, and characterized by convenient

operation, no rotary component, and electronic controlled amplitude and frequency. Its performance index is equal to that of the vibrator with sieve manufactured by German FRITSCH. In comparison with the traditional manual screen,it can greatly reduce labor intensity of operators and raise working efficiency. It is an essential laboratory screen for particle analysis.

Specifications:

Model TPZ-1

Shaking frequency: 500 times/min.

Shaking method: up and down

Shaking amplitude: 1.5 mm

Time setting: 0 – 60 min. selectable

Motor power: 25 W

Sieve size: Ø200 x 50 mm (9pieces) or Ø300 x 75mm (7pieces)

Sieve opening: 20 – 0.75 mm

Power supply: 220 V 50 Hz

Dimension: 430 x 430 x 750 mm

Weight: 16 kg

Vibrating Screen is a latest laboratory automatic screen designed and developed by our factory, applied to particle analysis in the fields of pharmacy, metallurgy, foods,cosmetics and grain, and characterized by convenient operation, no rotary component, and electronic controlled amplitude and frequency. Its performance index is equal to that of the vibrator with sieve manufactured by German FRITSCH. In comparison with the traditional manual screen,it can greatly reduce labor intensity of operators and raise working efficiency. It is an essential laboratory screen for particle analysis.

Shaking frequency: 500 times/min.

Shaking method: up and down

Shaking amplitude: 1.5 mm

Time setting: 0 – 60 min. selectable

Motor power: 25 W

Sieve size: Ø200 x 50 mm (9pieces) or Ø300 x 75mm (7pieces)

Sieve opening: 20 – 0.75 mm

Power supply: 220 V 50 Hz

Dimension: 430 x 430 x 750 mm

Weight: 16 kg

Test sieve kit for gravel

Includes twelve test sieves and one set of lid and cover.

Mesh size is shown as below:

2.36mm, 4.75mm, 9.50mm, 16.0mm, 19.0mm, 26.5mm, 31.5mm, 37.5mm, 53.0mm, 63.0mm, 0.75mm, 90.0mm.

Test sieve kit for sand and gravel aggregate

Includes seven dia. 300 test sieves and one set of lid and cover. Mesh size is shown as below:

9.50mm, 4.75mm, 2.36mm, 1.18mm, 600um, 300um,150um.

Test sieve kit for asphalt aggregate

Includes seven dia. 300 test sives and one set of lid and cover. Mesh size is shown as below:

0.075mm, 0.15mm, 0.3mm, 0.6mm, 1.18mm, 2.36mm,4.75mm, 9.5mm, 13.2mm, 16mm, 19mm, 26.5mm, 31.5mm,53mm

Test sieve kit for soil

Includes eleven dia. 200 test sives and one set of lid and cover. Mesh size is shown as below:

0.074mm, 0.25mm, 0.5mm,1.0mm, 2.0mm, 5mm, 10mm, 20mm, 40mm, 60mm
