V-Funnel

This apparatus is used to evaluate the segregation resistance of freshly mixed self-compacting concrete by the observation on the fl owing speed due to the difference of samples remaining period in the funnel. It consists of a funnel placed vertically on a supporting stand, having 10 litres capacity, stand mounted.
The upper edge of the funnel is smooth and reinforced, and the outfl ow orifi ce is equipped of an openable seal valve.

Funnel (width x deep): 515 x 75 mm
Height over all: 1000 mm
Weight approx: 20 kg

Smooth-textured,coated against corrosion,the shelf is adjustable.

Specification:

Funnel (width x deep): 515 x 75 mm
Height over all: 1000 mm
Weight approx: 20 kg

 Accessories These need to be ordered separately.

▲Stopwatch with the accuracy of 0.1 second for recording the flow time.

▲Straightedge for levelling the concrete.

▲Buckets with a capacity of 12-14 litres for taking concrete sample.
▲Moist sponge or towel for wetting the inner surface of the V-funnel.
