Wet Film Thickness Gauges
Be used to determine the thickness of liquid coatings. The measurements show an approximate information on the thickness of a liquid layer.
The Wet Film Thickness Gauge is available in rectangular or sexangular shape with different subdivisions of the measuring range each.
The tolerance of a particular gauge will be so certified at gauge midpoint and near its lower and upper recommended use limits and a suitable certifi cate will be included with the shipment of the gauge.
There are three levels of certifi cation available:
Full Certification of both sides of the gauge for Mil and Micron, Single Scale certification in Mil, Single Scale certifi cation in Micron.
Wet film thickness gauge (Rectangular)
Model WFR-A80/WFR-S80
Material: Aluminium(WFR-A80)
Material: Stainless steel (WFR-S80)
Size: 83 x 58 mm2 approx.
Thickness: 0.8 mm approx.
4 Measuring ranges: 1 to 6 Mil (25 to 152 Micro)
7 to 12 Mil (178 to 305 Micro)
14 to 30 Mil (356 to 762 Micro)
35 to 80 Mil (889 to 2032 Micro)
Scale indications: front Mil, rear Micro
Wet film thickness gauge (Hexagonal)
Model: WFH-A113/WFH-S113
Material: Aluminium(WFH-A113)
Material: Stainless steel (WFH-S113)
Thickness: 0.8 mm approx.
Measuring ranges: 0 to 113 Mil (25 to 3000 Micro)
Scale indications: front Mil, rear Micro
Wet film thickness wheels
Model: WFW-S150
Material: Stainless steel (WFW-S150)
Measuring ranges: 0 to 150 Micro
Accuracy: 15 Micro
