DUAL MASS DYNAMIC CONE PENETROMETER
(DCP) K-100 8kg or 4.6kg hammer, 57.5 cm. fall
Standard: ASTM D 6951-03
Model K-100 FEATURES:
• This application describes measurement of the penetration rate of the model K-100 DCP(dynamic cone penetrometer)with a single mass or dual-mass.
• The K-100 Standard Kit measures the shear strength of soil with a CBR between 0.5-100. Affordably priced, this kit is for local engineers and geotech fi rms. With it the user can produce CBR value profi les in the fi eld. It comes with a 30" drive rod (actual penetration depth 28 1/4"), 25 disposable cones and a cone adapter for fast and easy extraction of the instrument from hard soil.
• Additional disposable cones, cone adapters, and hardened points are available.
• One year warrantee against any manufacturing defects.
Model K-100 FEATURES:
• This application describes measurement of the penetration rate of the model K-100 DCP(dynamic cone penetrometer)with a single mass or dual-mass.
• The K-100 Standard Kit measures the shear strength of soil with a CBR between 0.5-100. Affordably priced, this kit is for local engineers and geotech fi rms. With it the user can produce CBR value profi les in the fi eld. It comes with a 30" drive rod (actual penetration depth 28 1/4"), 25 disposable cones and a cone adapter for fast and easy extraction of the instrument from hard soil.
• Additional disposable cones, cone adapters, and hardened points are available.
• One year warrantee against any manufacturing defects.
COMPRISES:
K100 Upper assembly (Stainless Steel) includes:
K012 DCP User’s Manual
K103 Quick-Connect Upper Rod K450 Pins with Clips, 2 per package
K102 Handle K500 Vertical Scale, 40”
K200 Dual Mass Hammer K510 Foot for Vertical Scale
K1330 Drive Rod 30” Stainless Steel with end cap K530 Upper Attachment for Vertical Scale
K420 Hex Key, 1/4”, “Allen” Wrenc. Type K700 Reusable Hardened Point
K430 3-in-ONE Oil K800 Adapter for Disposable Cones
K445 Wrences. 9/16”, open end, black K900 Disposable Cones, Pkg of 25
K011 CD of DCP User’s Manual & Excel® Template P-1720 Alloy Aluminum Carrying Case
ACCESSORIES AND SPARE PARTS: (need to be ordered seperately)
K133775 37.75” Drive Rod (Penetration to 35.75”) (Stainless Steel) with end cap
K1348 Stainless Steel 48” Drive Rod
K1312 12” Drive Rod for use with 24” Extension Rods K1348S Extra Strong 48” Drive Rod
K1724 Extension Rod 24” for use with 12” Drive Rod in weak soil
K133775S Extra Strong 37.75” Drive Rod
